ZTC-700B Automatic Book Cover Inner Laminating Machine (CCD) combines visual positioning technology and automatic laminating function. The machine uses visual systems such as cameras to identify and locate the workpiece, and then automatically and accurately laminates the lining material at the appropriate position to ensure the perfect fit between the lining and the packaging box, reducing the impact of human factors on product quality. Its precise positioning and laminating capabilities can ensure the perfect presentation of the inside and outside of the packaging box, and play an important role in the packaging production of high-end products.
| Model | ZTC-700B | |
| Maximum size | mm | 450×700 |
| Minimum size | mm | 140×190 |
| Board thickness | mm | 1-3 |
| Paper weight | g | 105-210 |
| Maximum speed | Pieces/min | 25-38 |
| Positioning accuracy | mm | ±0.1 |
| Power supply | kw | 14.5 |
| Machine weight | kg | 3000 |
| Dimension (LxWxH) | mm | 6500×2200×1850 |
Share your box type, dimensions, materials, target output and factory conditions. Horda will help evaluate the suitable machine configuration for your project.
Tell us your material, size range and capacity. We will reply with a tailored quotation.
